30" Whirlpool 5.8 Cu. Ft. Smart Slide-in Gas Range - WEG750H0HB
30" Whirlpool 5.8 Cu. Ft. Smart Slide-in Gas Range with EZ-2-Lift 8482 Hinged Cast-iron Grates1 - WEG750H0HZ
30" Whirlpool 5.8 Cu. Ft. Smart Slide-in Gas Range with EZ-2-Lift 8482 Hinged Cast-iron Grates1 - WEG750H0HV
30" Whirlpool 5.8 Cu. Ft. Smart Slide-in Gas Range - WEG750H0HW
30" Whirlpool 5.8 Cu. Ft. Smart Slide-in Gas Range - WEG750H0HB
![](/img/brandlogo/brand_logo_23.png)
External Dimensions
Dimensions shown are for planning purposes only. For complete information, see Installation Instructions packed with product.
Depth : 28 5/8
Height : 36
Width : 29 7/8
Depth With Door Open 90 Degree : 48 7/8
Key Features
Scan-to-Cook Technology : Get the right settings every time. Scan a frozen food barcode with your smartphone or tablet and send recommended or customized cooking instructions straight to your oven for dinner done the way your family wants it.4
Touchscreen : Get instant access to the settings you use most with an intuitive touchscreen that learns, adapts and suggests customized presets based on your family's routines.
Voice Control : Keep up with the kitchen or laundry no matter what you’ve got on your hands. Control your appliance with simple voice commands when you sync it with your smart home assistant5.
EZ-2-Lift Hinged Cast-Iron Grates1 : Get quick access to spills on the cooktop with our industry-first EZ-2-Lift hinged cast-iron grates1. The hinged design allows you to wipe up under them without removing them entirely. For a more thorough clean, the grates are also dishwasher-safe.
Smart Appliance : Care for your family from your smartphone or tablet3.
Multi-Step Cooking9 : Make multi-step meals more simple. Use your smartphone or tablet to send multiple cooking instructions to the oven all at once10. The temperature automatically adjusts based on the recipe you enter for great results without having to monitor your meal.
Frozen Bake Technology : Skip preheating with Frozen Bake technology. Cook frozen food with preprogrammed settings that automatically adjust cooking times so you can get select dinner items like pizza and lasagna from the oven to the table in less time6.
True Convection Cooking : Cook foods faster with the addition of a third element plus a fan that distributes hot air evenly over, under and around food so dinner is ready when they are.
Fingerprint-Resistant : Hide fingerprints and smudges with steel that easily wipes clean. Available in Black Stainless and Stainless Steel colors.
SpeedHeat Burner : Get dinner to the table fast with this burner that generates the high heat needed to sear and boil quickly.
AquaLift Self-Cleaning Technology
Center Oval Burner : Easily fit large griddles and other longer cookware on this fifth burner so they heat evenly on the range top.
FlexHeat Burner : Get evenly distributed high heat you need for rapid boiling and searing or the lower temperatures necessary for more delicate dishes, all in one.
Nest Learning Thermostat Integration : Integrate your Nest Learning Thermostat with the mobile app to be alerted if your oven is left on while you're away7.
Remote Start : With remote start enabled, use your smartphone or tablet to remotely turn your oven on so it's heated up and ready to cook meals when you are8.
Party Mode : Start preparing for guests from your smartphone or tablet. With remote start enabled, this mode automatically turns on the Keep Warm setting so dishes stay ready to serve11.
Control Lock Mode : Use your smartphone or tablet to remotely disable the control panel to avoid unintended use12.
Enhanced Troubleshooting : Get immediate support for quick solutions by using your smartphone or tablet to access troubleshooting videos13.
Guided Service : Keep track of scheduled appointments and make sure issues are known using the mobile app to send data from the appliance directly to Whirlpool brand customer service14.
Sabbath Mode : Use your smartphone or tablet to remotely set the oven to remain on the "Bake" setting at a constant . When this mode is enabled, displays, tones and all other cooking and cleaning cycles are disabled.
Convection Conversion : Easily get the right convection cooking temperature. Your oven automatically converts traditional recipes for convection cooking, adjusting cooking times and temperatures for you.
Temperature Sensor : Get evenly baked food with a sensor that monitors oven temperature and adjusts the cooking elements.
Rapid Preheat : Save time with 20% faster preheating1716. A rear fan combined with the use of all of the elements helps to heat the oven quickly.
Griddle : Grill vegetables, fajitas and other favorite foods quickly and easily on the included griddle.
5.8 cu. ft. Capacity : Cook even your largest meals with 5.8 cu. ft. capacity.
Large Oven Window : Keep an eye on your meal through the large oven window.
Dishwasher-Safe Knobs : Remove the dishwasher-safe knobs for easier cleaning.
#1 Selling Appliance Brand in the U.S.A.2
Oven Features | |
---|---|
Number of Oven Racks | 3 |
Convection Cooking Technology | Convection |
Convection Cooking Technology | Bake Broil Roast Both |
Convection Cooking Technology | True |
Convection Element Power (watts) | 900 |
Broiler Location | Top of Oven |
Broiler Element Power | 11,000 BTU |
Hidden Bake Element | Yes |
Bake Element Power | 18,000 BTU |
Self-Cleaning | AquaLift Self Clean |
Light Type | Incandescent |
Power On Indicator Light | No |
Hot Surface Indicator Light | No |
Heating Element On Indicator Light | No |
Automatic Convection Conversion Temperature Adjust | Yes |
Number of Oven Lights | 1 |
Number of Rack Guides | 7 |
Oven Rack Type | 2 Standard and 1 Max Capacity |
Cooktop Features | |
Grate Details | Dishwasher Safe, Hinged, Matte Finish, Porcelain Coated Cast Grates |
Number of Grates | 2 |
Right Rear Element-Burner Type | Burner |
Right Rear Element-Burner Power | 9500 BTU |
Right Front Element-Burner Type | Dual Flame |
Right Front Element-Burner Power | 13,000 BTU |
Left Rear Element-Burner Type | Simmer |
Left Rear Element-Burner Power | 5000 BTU |
Left Front Element-Burner Type | High Output |
Left Front Element-Burner Power | 17,000 BTU |
Center Rear Element-Burner Type | Oval Burner |
Center Rear Element-Burner Power | 10,000 BTU |
Number of Burner | 5 |
Cooktop Surface Material | Porcelain Coated Steel |
Cooktop Element Style | Gas Burner |
Cooktop Surface Color | Black |
Configuration and Overview | |
Capacity | 5.80 |
Star K Compliant | Yes |
ADA Compliant | ADA Height and Operation Compliant |
Size | 30 |
Range Type | Slide-in |
Fuel Type | Gas |
CONTROLS | |
Drawer Type | Storage Drawer |
Handle Material | Metal |
Handle Type | Reach Through Handle |
Selections | Audible Signal, Broil, Cancel/Off, Clock, Control Lock, Convect Modes, Cook Time Indicator, Delay Start, Easy Convect Baked Goods, Easy Convect Meats, Easy Convect Pizza, Energy Save Mode, Favorites, Frozen Bake, Keep Warm Setting, Language Conversion, Proofing, Rapid Preheat, Sabbath Mode, Start Time, Stop Time, Timer |
ADA Compliant | ADA Height and Operation Compliant |
UL | UL |
Star K Compliant | Yes |
