External Dimensions
Dimensions shown are for planning purposes only. For complete information, see Installation Instructions packed with product.
Depth : 27 3/4
Height : 46 7/8
Width : 29 7/8
Depth With Door Open 90 Degree : 46 5/8
Key Features
Precision Cooking System : The Precision Cooking system uses sensor heating to help ensure each meal is cooked evenly.
Better Built Components : A shatter-resistant cooktop and heavy-duty door hinges combine with premium ball-bearing drawer glides to help ensure that these ranges are built to last for years.
Variable Broil : Variable broil brings the best results out of broiling with just the right temperatures for quick-cooking tasty meals.
Shatter Resistant Cooktop : Stringently tested for ultimate reliability, the glass resists scratches, chips and cracks.
10-Year Limited Parts Warranty1 : With a 10-year limited parts warranty1 on the glass cooktop, elements and cavity, we built these ranges tough enough to keep cookin' for years.
Designed, Engineered, and Assembled in the U.S.A. : Maytag® ranges are designed, engineered and assembled in the U.S.A.
| CONTROLS | |
|---|---|
| Drawer Type | Storage Drawer |
| Handle Material | Metal |
| Handle Type | Reach-Through Handle |
| Selections | Audible Signal, Control Lock, Cook Time Indicator, Delay Start, Keep Warm Setting, Sabbath Mode |
| ADA Compliant | No |
| UL | UL |
| Oven Features | |
| Oven Rack Type | Standard |
| Number of Rack Guides | 5 |
| Number of Oven Racks | 2 |
| Convection Cooking Technology | Thermal |
| Convection Cooking Technology | No |
| Convection Cooking Technology | None |
| Broiler Location | Top of Oven |
| Broiler Element Power | 3400W |
| Bake Element Power | 2400W |
| Hidden Bake Element | Yes |
| Self-Cleaning | Adjustable Self Cleaning |
| Light Type | Incandescent |
| Power On Indicator Light | Yes |
| Hot Surface Indicator Light | Yes |
| Heating Element On Indicator Light | Yes |
| Automatic Convection Conversion Temperature Adjust | No |
| Number of Oven Lights | 1 |
| Cooktop Features | |
| Right Rear Element-Burner Type | Radiant |
| Right Rear Element-Burner Power | 1200W |
| Right Rear Element-Burner Size | 6" |
| Right Front Element-Burner Type | Radiant |
| Right Front Element-Burner Size | 9" |
| Right Front Element-Burner Power | 2500W |
| Left Rear Element-Burner Type | Radiant |
| Left Rear Element-Burner Size | 6" |
| Left Rear Element-Burner Power | 1200W |
| Left Front Element-Burner Type | Radiant |
| Left Front Element-Burner Size | 9"/6" |
| Left Front Element-Burner Power | 3000W |
| Center Front Element-Burner Type | Warming |
| Center Front Element-Burner Size | 6" |
| Center Front Element-Burner Power | 100W |
| Number of Burner | 5 |
| Cooktop Surface Material | Glass |
| Cooktop Surface Color | Black |
| Cooktop Element Style | Smoothtop |
| Configuration and Overview | |
| ADA Compliant | No |
| Capacity | 5.30 |
| Range Type | Freestanding |
| Size | 30 |
| Fuel Type | Electric |
